Building a summary sheet

Building a summary sheet

  • Template files
  • Key operation
  • Available information
  • Key populations available
  • Populations available for each type of object
  • Filters
  • Filter operators
  • Examples
  • Project attributes
  • Project team
  • Project reporting lines
  • Errors
đźš©

Summary sheets - new generation (beta)

In this version, you can more easily import data into a PowerPoint or Word file:

  • attributes,
  • hierarchical relationships,
  • project roles (project team).

A summary sheet contains keys that link the data in your platform to what will be entered in the sheet.

The model sheet is therefore built by calling up these keys, in a Word or PowerPoint file.

This template file is then added to the platform. See Add a summary sheet template to the platformAdd a summary sheet template to the platform

đź“Ž

Memo characters used:

  • $ represents information that will be replaced by a value of Project MonitorProject Monitor.
  • POP represents a population key for displaying information about certain objects
  • .SOUSPOP The point allows you to target a specific subpopulation.
  • {attribute} Braces are used to display a attribute
  • [FILTER=1] the cRocksets allow you to add filters with operators.
  • ; The semicolon is used as a separator to add multiple filters.

Template files

đź“Ž

Here are some sample summary sheets:

fiche_complete.docx122.1KB
project_template.pptx1.8 MiB

Key operation

For project attributes, attachments or roles to appear in a summary sheet, they must be entered in a certain way in your template file.

This code must have this form: ${CODE_ATT}where CODE_ATT can be :

  • attribute code on the platform Building a summary sheet Available informationBuilding a summary sheet Available information This attribute code will be replaced by theattribute value present in your project. attribute keys can be in a text field, or contained in a table.
    • đź’ˇ

    To find out theattribute code, access the list of project attributes via AdministrationAdministration > ProjectProject.

  • project role code Building a summary sheet - Project teamBuilding a summary sheet - Project team This code will be replaced by information from the project team, such as the names of the people who have this or that role.
  • code for a hierarchical structure link Building a summary sheet - Project reporting linesBuilding a summary sheet - Project reporting lines

    • This code will be replaced by information on your project's hierarchies, levels and hierarchical values.

🚨

The formatting of a rich text attribute is preserved as far as possible (colors, formatting), but may be slightly different. For example, images and tables are not included in new-generation summary sheets for the time being.

Available information

🚨
Please note! All codes quoted are from an integration platform. Codes may have been modified on your platform. It's impossible to make an exhaustive list of all available attributes. What's more, there are probably attributes on your platform that you've created yourself.
icon

Projects

For projects, it is possible to display:

  • Label: PROJECT_TITLE
  • Code: PROJECT_CODE
  • Icon: ICON
  • Long label: LONG_PROJECT_TITLE
  • Description: PROJECT_DESCRIPTION
  • status status
  • Project start date: PROJECT_START_DATE
  • Project end date: PROJECT_END_DATE
  • Project creation date: PROJECT_CREATION_DATE
  • Date of update: PROJECT_UPDATE_DATE
  • scheduling date: RESOURCE_PLANNING_DATE
  • Project completion date: PROJECT_CLOSED_DATE
  • project manager PROJECT MANAGER
  • template template
  • Parent project: FATHER PROJECT
  • Project weather forecast: ATT_WEATHER

and all attributes with codes

‣
Image attribute
icon

Project roles

For project roles (project team), it is possible to display:

  • The wording of the role LABEL
  • role identifier role ID
  • The role code role CODE
  • role description role DESCRIPTION
icon

Users

For users, it is possible to display:

  • Login: LOGIN
  • First name: FIRSTNAME
  • The name: LASTNAME
  • First name and last name: FULLNAME
  • Description: DESCRIPTION
  • The function: FUNCTION
  • The email: EMAIL
icon

Hierarchies and level values

For hierarchies and level values, it is possible to display:

  • The wording: LABEL
  • The identifier of the structure structure value ID
  • The structure code structure structure value CODE
  • Description of structure structure value DESCRIPTION

Key populations available

A population is what an object can contain: for example, a project has hierarchical relationships or roles.

You can call within an array.

To get a list of an object's population, you must first insert a table into the PowerPoint template slide or Word template file.

The content of the table must comply with the following format:

  • The first line must be the table header . The text formatting is retained.
  • The second line contains the populations and keys to be displayed in the table.
    • ⚠️
    Please note that text formatting in cells is not retained.

The keys must be in the form $POP{ATT_CODE}where CODE_ATT is theattribute codeattribute the platform and POP the name of the object.

For example: $PROJECT{LABEL} to display the names of the projects.

You can target a subpopulation by combining keys.

For example: $ROLEUSER{FIRSTNAME} to display the first names of users who have a role project.

Populations available for each type of object

Subject/Population
Object/population keys
Available subpopulation
Subpopulation keys
structure
HIERARCHY
structure value
VALUE or .VALUE
role
ROLE
User
USER or .USER

Filters

It is possible to filter what you want to display in a list using a code/value combination.

A filter materializes as follows. It is located [in brackets] and after the population key.

For example: $ROLE[CODE=ROLE1] to display all roles that have a code equal to "ROLE1"

It is also possible to combine multiple filters using a separator: ;.

For example: $ROLE[CODE=ROLE1;DESCRIPTION=CDP] to display all roles that have a code equal to "ROLE1" AND that have the description "CDP."

To target a subpopulation, you can combine filters:

For example: $ROLE[DESCRIPTION=CDP]USER[CODE=CDP]{LABEL} to display tAll role labels with the description "CDP" and users with the code "CDP."

Filter operators

Several filter operators are available:

Equal to
=
Different
≠
Strictly less than
<
Strictly greater than
>
Less than or equal to
<=
Greater than or equal to
>=
Check for nullity
IS_NULL , IS NULL , IS WORTHLESS , EST_NULL , IS NULL , EST_NULL , =NULL, = NULL , =NULL , = NULL , = NULL , =NULL , =null, = null
Check for non-nullity
IS_NOT_NULL, IS NOT NULL, IS NOT NULL, NOT_NULL, IS NOT NULL, NOT_NULL, =NOT_NULL, = NOT NULL, =NOT_NULL, = NOT_NULL, = NOT_NULL, =NOT_NULL, ≠null, ≠ null
Check that a list is not empty
IS NOT EMPTY, IS NOT EMPTY, IS_NOT_EMPTY, NOT_EMPTY
Check that a list is empty
IS EMPTY, IS EMPTY, IS_EMPTY, EST_EMPTY

Examples

Project attributes

To view different attributes assigned to a project:

  1. Add a table to your template file.
  2. Complete the table with the desired data.
Project
${PROJECT_TITLE}
Code
${PROJECT_CODE}
Icon
${ICON}
Long label
${LONG_PROJECT_TITLE}
Description
${PROJECT_DESCRIPTION}
status
${status}
Duration
From ${PROJECT_START_DATE} to ${PROJECT_END_DATE}
Project creation date
${PROJECT_CREATION_DATE}
Update date
${PROJECT_UPDATE_DATE}
Resource scheduling date
${RESOURCE_PLANNING_DATE}
Date project closed
${PROJECT_CLOSED_DATE}
project manager
${PROJECT MANAGER}
template
${template}
Father project
${FATHER PROJECT}
Project weather
${ATT_WEATHER}

Project team

To display the roles and users assigned to a project :

  1. Add a table to your template file.
  2. Complete the table with the desired data.

Here is an example of a configuration listing information on roles and users:

role $ROLE{LABEL}
User: $ROLE.USER{FULLNAME}
($ROLE{ID}, $ROLE{CODE})
($ROLE.USER{ID}, $ROLE.USER{LOGIN})
$ROLE{DESCRIPTION}
$ROLE.USER{FUNCTION} $ROLE.USER{EMAIL}

Project reporting lines

To display attachments for a project :

  1. Add a table to your template file.
  2. Complete the table with the desired data.

Here's an example of how to configure a table listing information on hierarchical links:

structure
Value
$HIERARCHY{LABEL} $HIERARCHY{CODE}
$HIERARCHY.VALUE{LABEL} $HIERARCHY.VALUE{CODE}
structure Detail
Value
$HIERARCHY{DESCRIPTION} $HIERARCHY{ID}
$HIERARCHY.VALUE{DESCRIPTION} $HIERARCHY.VALUE{ID}
‣

Errors
